Serie MP – Slurry Pumps

To ensure maximum abrasion resistance, all components of the MP line that come into contact with the fluid are made of high-chromium white iron (CAC), an extremely hard material (over 600 BHN), ideal for handling slurry, sand, and other abrasive solids. The suction cover is made of ductile iron, while the bearing frame is cast iron. The suction cover is protected by a wear plate, which isolates it completely from fluid contact, extending its lifespan. All MP pumps use adjustable wear plates instead of traditional wear rings, helping maintain efficiency during operation and simplifying maintenance.

It is a solution for applications where the pump might run dry. It includes an auxiliary gland and oil reservoir that lubricate the seal faces and prevent dry running during priming, re-priming, or standby operation. The system features continuous circulation and cooling of the lubricant and seal faces, and allows the pump to run dry for hours without damaging the mechanical seal.

Cornell’s manure pumps come equipped with the patented Cycloseal sealing system, which leverages cyclonic action to extract solids and abrasive substances from the seal area while simultaneously purging air and gas pockets. This groundbreaking technology extends the lifespan of the seal.

A patented, fully automated system for rapid priming or re-priming without constant monitoring. With oversized suctions, they deliver high flow, reduced friction losses, and enhanced suction lift, making them easily handle large solids and air/liquid mixtures. Redi-Prime also maintains premium hydraulic efficiency to reduce energy consumption.

Cornell Pulse is a new method to measure pump temperature and vibration in real time. The device is a small wireless unit, less than 2” in circumference, which is mounted on the pump and takes readings when prompted by the user via a mobile app. Pulse is designed to withstand tough wash-down conditions and can last up to five years with daily measurements.

Suitable for pumping spherical solids, ensuring excellent efficiency and head. Can be used for solids larger than 2".
